- #SHIMANO FLIGHT DECK SC 6501 MANUAL MANUAL#
- #SHIMANO FLIGHT DECK SC 6501 MANUAL BLUETOOTH#
Once a device is paired, you should not have to disconnect it or remove power from it to continue the process with other devices. If you go through step 6 and it doesn't work you may need to disconnect the shift levers individually and try again. While Shimano's online documentation on this is rather sparse, the Di2 7900 system description says the system logic and communication circuits are inside the front derailleur.
#SHIMANO FLIGHT DECK SC 6501 MANUAL MANUAL#
The graphics shown in the SC-7900 supplemental manual imply that the right and left shift levers are separate devices, but they are powered from the same battery and connected to the system at a single point.
Do not exit the pairing mode until everything is paired, or you will have to start over. Note that all of this must be done in one pairing session.
Once the shift system is paired, you can pair the heart monitor and speed sensor.
In that case, remove the battery again, reconnect the rear derailleur and repeat the scan. If this works, the front and rear derailleurs are separately paired devices. Repeat step 4 and press 'retry' (the Select button) on the SC-7900 to repeat the scan.
If the pairing does not complete, remove the battery, then disconnect the electrical cable from the rear derailleur. The pedal on that side should be in the lowest position to minimize any effect of radio signal reflections from it. Immediately press the Select and Set buttons on the SC-7900 to put it in scan mode and hold the SC-7900 about 1-2 feet (30-70 cm.) away from one side of the bike. If you can lock the clamp in place while holding the battery so it does not slip even a little bit from the contacts you may do so.ĭo not give it a second push 'for insurance' at this time this may generate a contact bounce. Push the shift system battery into place smoothly and hold it. If there is a power switch on the system, turn it on first. I suggest removing the SC-7900 from its bracket and parking it someplace where you can conveniently grab it when you reinstall the battery in the shift system. Set the SC-7900 into pairing mode as described in the manual (latest version can be downloaded ). This will ensure that any power bypass capacitors in the system are fully discharged and the circuitry will completely reset when the battery is put back in. Click the shift buttons on each lever, then use a piece of wire or suitable tool to short the battery contacts of the shifting components (NOT WITH THE BATTERY INSTALLED!) for 10 seconds. Clean the battery terminals with a clean paper towel moistened with isopropyl alcohol. Wipe the battery contacts of the shift system with a cotton swab moistened with isopropyl alcohol (get straight alcohol if you can, rather than the 70% rubbing alcohol mix). Remove the batteries from all components of the system except the SC-7900, including the heart rate monitor and the speed sensor. #SHIMANO FLIGHT DECK SC 6501 MANUAL BLUETOOTH#
Do not let anyone play with R/C toys within 30 feet while you are doing the pairing, and turn off Bluetooth devices to be really sure. If you have extraneous gear such as metal water bottle brackets mounted near the system controller / battery pack, remove it for this operation. Since this is done with low power high frequency radio signals, interference and reflections can be an issue.
1626 Answers SOURCE: It is apparently critical for the success of the pairing operation that initial power-up of the component to be paired be done cleanly, with little or no contact bounce when the battery is inserted. By filling in the form below, your question will appear below the manual of the Shimano Flight Deck SC-6500. Have a question about the Shimano Flight Deck SC-6500 but cannot find the answer in the user manual? Perhaps the users of can help you answer your question.
